10mm Aluminum Honeycomb Panel Width 48" And 60" Standard OEM

Name: 10mm Aluminum Honeycomb Panel Width 48quot And 60quot Standard OEM
Brand: Alumetal
Price: 1 USD

Brand Name : Alumetal

Model Number : ahp

Place of Origin : Shanghai, China

MOQ : 500

Price : To be negotiated

Packaging Details : Standard export wooden case

Product name : 48" and 60" standard OEM Aluminum Honeycomb Panels 10mm

Coating : Clear Epoxy Primer Mill Finish Bond and/or Paint Ready

Color : Custom

width : 48" & 60" standard

Thickness : 1/8" to 3" standard

Length : Up to 190" standard

Protective film : OEM Accepted

Certificate : ASTM

Contact Now

48" and 60" standard OEM Aluminum Honeycomb Panels 10mm

Aluminum honeycomb panel is a honeycomb sandwich panel with honeycomb structure as the core, which is inspired by natural hexagonal honeycomb. The unique honeycomb structure makes it lighter than other materials of the same volume, with good stiffness and overall stability, and the aluminum honeycomb panel also has the advantages of sound insulation and heat insulation. Aluminum alloys are neither radioactive nor volatile. They can be completely recycled, saving resources and energy and minimizing environmental pollution. This makes the honeycomb aluminum panel a new energy-saving, environmentally friendly and healthy material.

Aluminum Alloy	AA3003 H18, AA5052 H18
Total Panel thickness	4mm, 8mm, 10mm, 15mm, 25mm, Max 500mm
Aluminum Skin thickness	0.5mm, 0.8mm, 1mm, 1.5mm, Max 3mm
Coating:	PVDF, PE, Anodized, Mill Finished, Embossed, Granite etc
Length:	2440mm, 3000mm, 3500mm, 5800mm, Max 10000mm
Width:	1000mm, 1220mm, 1250mm, 1500mm, Max 2200mm
Honeycomb Core Foil Thickness:	0.02mm, 0.04mm, 0.05mm, 0.06mm, 0.08mm Max 0.1mm
Honeycomb Core Cell Size:	Micro-Aperture Honeycomb:1/10”(2.6mm), 1/8”(3.17mm), 1/6”(3.47mm), 1/5”(5.2mm), Regular Honeycomb: 1/4”(6.35mm), 1/3”(8.47mm), 3/8 ”(9.53mm), 1/2”(12.7mm), 3/4”(19.05mm), 4/5”(20.32mm), 1”(25.9m)
Honeycomb Core Cell Side Length:	Micro-Aperture Honeycomb:1.5mm, 1.83mm, 2mm,2.5mm, 3mm, Regular Honeycomb: 4mm, 5mm, 6mm, 7.5mm, 10mm, 12mm, 15mm
Edge:	Close Edge, Open Edge

Click Below to Download Color Chart
Alumetal Color Chart.pdf

10mm Aluminum Honeycomb Panel Width 48" And 60" Standard OEM

FAQ

Q1.What is your MOQ, Delivery Time, Payment?

A1:1. MOQ (Minimum Order Quantity): 500m² but it can be less if we have stocks

2. Delivery Time: within 15 days after receiving deposit

4. Payment: 30% TT in advance ,70% against BL of copy or LC

Q2.Do you have any test certificates?

A2:Yes, stable good quality is key for long time business cooepration.

Factory have passed ISO9001:CE SGS, etc .

Q3.Do you service OEM?

A3: Yes, OEM accept. Just need to give us yours logo, we will send some protective film design for your choose

Q4.What's the available panel size and thickness?

A4: 1. Width: 1000-1575mm; 1220mm, 1250mm, 1500mm are recommended.

2. Length: accept custom length, recommend 2440mm, 3050mm, 4050mm, 5000mm

3. Panel Thickness:2mm-6mm; recommend 3,4mm

4.Aluminum thickness:0.05-0.5mm

Q5.Do you offer sample?

A5: Yes, samples are available if you are interested in our product
